功用与百科/Brief Introduction：

机械适用了层次性三通管包装阀，适用性于水剂和膏霜类物品的包装，专门对高107硅橡胶107硅橡胶粘度废料（如浓酱、辣子酱、番茄酱、种衣剂、微乳剂、悬停剂等）的特效对比很深，且精确程度高。机械适用了PLC可代码把控，配上6寸大手触屏人与机器软件界面装置，适用半电脑半自动进瓶，半电脑半自动包装，半电脑半自动出瓶，电嚣，油路分配器元机件均适用了国际级企业品牌，事关了好品质的线质量和持续比较稳定的功效。本装备组成十分简单，的操作省事，是国內期望的造成高107硅橡胶107硅橡胶粘度废料的包装装备。机械标准配置了放到渗漏问题与拉丝工艺机的包装闷头，事关包装重新后无渗漏问题，无拉丝工艺机。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

特征/Characteristic：

◆操作装置——用三菱数控整体PLC操作装置，灌装生产线用量随机函数上下调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆运行工具栏显示——65英寸彩屏手触式运行工具栏显示，主观简便、安全管理靠谱Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆职能表改变——排料有防滴漏问题保护装置，可跟据废料特征配备下潜灌装线职能表。（此职能表还可以选购）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电气产品电气元件——均进行国际英文着名品店牌，确保防护生产专用设备的防护可靠性、准确的性好；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆自动化设备安全装置——机设备安全装置均用于高质304不锈不锈钢管作,予以想要相处废料能够用于316L另结算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆筛选法验测——实时公交筛选法，对工做出现客观表现。Counting test, real-time, intuitive reflect the yield of work.◆灌装设备论文检测——无瓶不灌、瓶数不高不灌Bottle filling test - no bottle no filling, not enough◆定期运营维护实际情况——滤油机具有GMP追求，可轻易拆解、清洁工作定期运营维护。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆掉换标准——根换装灌标准时，只需要方便修整，不累就搞定。Changing specifications - change the filling specifications, simply adjust, easy fix.◆的干净设置单单——设置单单了的干净架构设计，使丝机的作业室内环境更清潔卫生学。（此的干净设置单单应该标准配置）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术设备因素/technical parameters：

灌装线头数The number of filling head	8头（可供选择4、6、8、10、14个罐装头）8 hea🧜d (optional 4, 6, 8, 10, 12 filling head)
适用性瓶径 Applicable bottles Drive	Ф33-Ф100 mm
测量计算精度measure precision	±1%
罐装余量Canned capacity	150-1000ml
生孩子程度Production Capacity	2400-4000瓶/天2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
