用处与简价/Brief Introduction：

全一键液压泵式膏体酱灌装线设备机这是我公司适用市场的实际需求设计规划的新企业产品。此机用到SUS304铝合金液压泵式检定泵执行工作灌装线设备，且集一键上盖、一键旋盖、建筑机电电器为混合式，城市发展常用，占屋占地占地小，范围广技术应用于制药业、食材、化肥、医药化工、美妆品等行业中的全自动包装设计，具备GMP原则需求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优势/characteristic：

◆运用注塞泵式压力容器检验泵下达包装，适用人群多种多样浓稠度药液，导致精度较高；泵的空间结构运用快接式卸下来中介机构，利于刷洗、杀菌。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式计量校准泵连杆环金属才质依据市场及液态物质成分表的有差异 应用硅橡胶材料，四氟氯乙烯或许多金属才质，特色领域应用淘瓷金属才质。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC有效控制体系，变频器控速，自動化层次高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不装灌，主动记数工作。Lack of bottle filling, automatic counting function◆装量调控方便简洁，可以次调控都是剂量泵的充填量，也可采取很多剂量泵通过微幅调控；进行简单便捷，调控高效。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装线针头现有防漏滴传动装置，充填时前往瓶底包装线，慢上涨，避免 导致气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆该机可选用各不相同要求的可乐瓶，设定操作简单，可在间歇间内达到。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆设备按GMP的标准设计构思。The machine designed according to the requirements of GMP

技术工艺因素/technic parameter：

适用于塑料瓶子规格为Size of bottles	20-1000ml（给出规定为您加工定制）20-1000 - ml (according to your need）
可用于塑料瓶子截面积Apply the bottle diameter	¢20-¢150mm
使用盖子的规格Apply the lid specifications	¢20-¢70mm
产生力量 production capacity	四头灌装设备：1000-2500瓶/时间 Four filling head: 1000-2500 bottles per hour 八头罐装：2500-4000瓶/H Eight head filling: 2500-4000 bottles per hour 12头灌装生产线：4000-6000瓶/小时候 12 head filling: 4000-6000 bottles per hour
装量差值The load error	±1%
旋盖优秀率率Screw cover percent of pass	≥99%
电压power supply	380V，50HZ
电功率power	3.0KW
汽源gas sources	0.4-0.75MPA
访问速度操控speed control	直流变频调节variable speed
